USB 3.1 Dual ports PCI Express Card

$79.00 inc GST

USB 3.1 USB Type-A port

Categories: ,

Description

BUS PCI Express Spec 2.0, Dual-Lane (x2)
Controller PCI Express USB 3.1 Host controller, Asmedia ASM1142
USB Standard eXtensible Host Controller Interface (xHCI) Rev1.1
IRQ & IO Assigned by System
USB Communication
Interface Universal Serial Bus 3.1 / 3.0 / 2.0 / 1.1
Speed SuperSpeed+(10Gbps), SuperSpeed(5Gbps), High Speed (480Mbps), Full Speed (12Mbps), Low Speed (1.5Mbps)
No. of Port 2-port
PCB Connector USB 3.1 USB Type-A port
Protection ±15KV IEC61000-4-2 Air Gap Discharge
±8KV IEC61000-4-2 Contact Discharge
Power
Source PCIe Bus Power
Output Capacity USB Type-A Port:
+5VDC / Maximum 0.9A / each port
Note: Total power output capacity will be limited by system power supply.
Over Current Protection USB Type-A Port:
+6VDC / 1.1A / each port / PTC Fuse
Power Consumption 1.1 W @ 3.3V (board only without power output to USB device)
Driver Support
Windows Windows 7 (X86/X64)
Windows 8.x / 10 (X86/X64) (Windows in-box driver)
Linux Linux 2.6.31 or later (Linux OS already implemented USB 3.0 driver)
Environment
Operation Temperature 0 to 60°C (32 to 140°F)
Operation Humidity 5 to 95% RH
Storage Temperature -20 to 70°C (-4 to 158°F)
Regulatory Approvals
EMC CE, FCC, VCCI, BSMI
Green RoHS, CRoHS, WEEE
Physical Characteristics
PCB Dimension 79.3 x 68.5 mm
Bracket Standard 120 mm (Low Profile 80mm)
Bracket Space 1

*All pictures shown are for illustration purpose only.
