APC Back-UPS 550VA/330W Power-Saving UPS

APC Back-UPS 550VA/330W Power-Saving UPS

Desk Top, 230V/10A Input, 8x Aus Outlets, Lead Acid Battery, User Replaceable Battery

$199.00

Technical Specifications
Key Features
Output Connections

(4) Australian (Battery Backup)
(4) Australian (Surge Protection)

Nominal Output Voltage

230V

Nominal Input Voltage

230V

Input Connections

Australian

Cord Length

1.8 metres

Output
Max Configurable Power (Watts)

330 Watts / 550VA

Output Frequency (sync to mains)

47 – 63 Hz Sync to mains, 50 Hz +/- 0.1 % For 50 Hz nominal Unsynchronised

Topology

Standby

Waveform type

Stepped approximation to a sinewave

Output Voltage Tolerance

+/- 5% static and 100% load step

Transfer Time

6 ms typical : 10 ms maximum

Input
Input frequency

50/60 Hz

Batteries & Runtime
Battery type

Lead-acid battery

Typical recharge time

16hour(s)

Replacement Battery

APCRBC110

Expected Battery Life (years)

3 – 5

Battery Charge Power (Watts)

5 Watts

Communications & Management
Control panel

LED status display with on line : on battery : replace battery and overload indicators

Surge Protection and Filtering
Surge energy rating

310Joules

Data Line Protection

RJ45 analog phone line for phone/fax/modem/DSL, RJ45 network line – 10/100 base-T Ethernet

Filtering

Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical
Maximum Height

88mm

Maximum Width

180mm

Maximum Depth

302mm

Net Weight

5.5kg

Shipping weight

6.2kg

Shipping Height

128mm

Shipping Width

235mm

Shipping Depth

393mm

Colour

Black

SCC Codes

10731304275418

Environmental
Operating Temperature

0 – 40 °C

Operating Relative Humidity

0 – 95 %

Operating Elevation

0 – 9144metres

Storage Temperature

-15 – 40 °C

Storage Relative Humidity

0 – 95 %

Storage Elevation

0 – 9144metres

Audible noise at 1 metre from surface of unit

40.0dBA

Conformance
Approvals

A-Tick, C-Tick, CE, Telepermit

Equipment protection policy

Lifetime : 150000 AUD

Standard warranty

2 years repair or replace

Sustainable Offer Status
RoHS

Compliant
